106XL031 HTD Single Sided Toothed Timing Belt

Availability: In stock
Product SKU
106XL031
£5.99 £4.99


HTD belts have a curved tooth profile providing a positive drive between the belt teeth and the pulley grooves. The Belt is constructed of a flexible, durable chloroprene polymer which encapsulates the helically wound glass fibre tensile members. This gives the belt a high tensile strength and excellent fatigue life with virtually no stretch. The belts teeth are protected by a low friction woven nylon which protects the tooth surface from wear and aids in quiet efficient running.

Supplied in one of the following high quality brands: Dunlop, Challenge, Medway.

  • Belt Width: 7.94mm = 5/16 inch

  • Belt Length: 10.6 inch

  • Pitch: 5.08mm = 1/5 inch

  • Number of Teeth: 53

  • Temperature Range: -25°C - +100°C

More Information
Hazardous ItemNo
