483PJ/190J Dunlop Poly V Multiple Ribbed Belt J Section 2.34mm - 483mm /19" Long

Availability: In stock
Product SKU
483J/RIB DUN
As low as £5.99 £4.99


The Poly-V belt is a single, endless belt with longitudinal V-shaped ribs that mate perfectly with the V-grooves in the pulleys (sheaves). It combines the convenience of a thin, one-piece flat belt with the strong gripping traction of multiple V-belts to make the Poly-V belt far better than either for many applications. The approximate belt width is the number of ribs multiplied by 2.34mm. To distribute the drive load evenly across the full width of the sheave, the Poly-V belt is built as a single unit with a completely supported, uninterrupted tension member. There is no matching problem. No separate belts to turn over, grab, slip, or interfere with each other. The thin cross section profile allows use of smaller pulleys than standard V-belts, and Poly-V belts handle speed ratios of 40:1. With all this capacity, the Poly-V belt tracks properly without special guides, flanges, crowns, or deep grooves. And it resists seating in the grooves, so speed ratios remain more consistent and output speed remains more uniform.

Choose Number of Ribs Required.

  • Belt Length: 483mm = 19 inch

  • Tooth Pitch: 2.34mm

  • Belt Height: 3.6mm - 4.5mm

Dunlop poly ribbed v belts offer reassurance of a premium brand and are produced to a high quality standard.

Please Note: In the unlikely event that we should not have Dunlop stock available then a quality brand will be supplied.

More Information
Hazardous ItemNo
